These pumps do not have an internal bypass. A bypass style regulator and return line are required.
NOT FOR USE WITH METHANOL!
Will not work with E-85 or Diesel!
This pump is not designed to use a standard conical seat style union in the inlet or outlet of the pump. Example: Part # AT981510ERL. Use of this style fitting will block flow and WILL lead to poor performance and pump failure. The ONLY correct fitting to use is a contoured port fitting with an O-ring seal such as :Part # AT985010ERL.
These pumps do not have an internal bypass. A bypass style regulator and return line are required.
NOT FOR USE WITH METHANOL!
Will not work with E-85 or Diesel!
This pump is not designed to use a standard conical seat style union in the inlet or outlet of the pump. Example: Part # AT981510ERL. Use of this style fitting will block flow and WILL lead to poor performance and pump failure. The ONLY correct fitting to use is a contoured port fitting with an O-ring seal such as :Part # AT985010ERL.
| Download Name | File Size |
| holleyfuelsystems_chart1.pdf | 360.32KB |
| 199r11109.pdf | 975.52KB |
| Application | Universal |
| Emission Code | 5 |
| Forced Induction HP@43PSI | 1150 |
| Forced Induction HP@60PSI | 1050 |
| Forced Induction HP@8PSI | 1430 |
| Free Flow GPH | 160 |
| Fuel System | Carbureted, EFI |
| Fuel Type | Gasoline |
| GPH@43PSI | 127 |
| GPH@60PSI | 113 |
| GPH@8PSI | 155 |
| Inlet Size | 2 x 10 AN O-Ring - 7/8-14 SAE |
| LPH@43PSI | 480 |
| LPH@60PSI | 427 |
| LPH@8PSI | 587 |
| Material | Aluminum |
| Naturally Aspirated HP@43PSI | 1600 |
| Naturally Aspirated HP@60PSI | 1330 |
| Naturally Aspirated HP@8PSI | 1800 |
| Outlet Size | 10 AN O-Ring - 7/8-14 SAE |
| Part Type | Electric Fuel Pump |
| Product Type | Fuel Pump |
| Proposition 65 | www.P65Warnings.ca.gov |
| Pump Body Color | Black Anodized |
| Special Offers | Summer Sale |
| Warranty | Limited 90 Day |
