MSD Digital 6AL Ignition Control, Red 6425

MSD Digital 6AL Ignition Control, Red 6425
MSD Digital 6AL Ignition Control, Red 6425MSD Digital 6AL Ignition Control, Red 6425MSD Digital 6AL Ignition Control, Red 6425MSD Digital 6AL Ignition Control, Red 6425MSD Digital 6AL Ignition Control, Red 6425MSD Digital 6AL Ignition Control, Red 6425MSD Digital 6AL Ignition Control, Red 6425MSD Digital 6AL Ignition Control, Red 6425MSD Digital 6AL Ignition Control, Red 6425MSD Digital 6AL Ignition Control, Red 6425MSD Digital 6AL Ignition Control, Red 6425MSD Digital 6AL Ignition Control, Red 6425MSD Digital 6AL Ignition Control, Red 6425MSD Digital 6AL Ignition Control, Red 6425MSD Digital 6AL Ignition Control, Red 6425MSD Digital 6AL Ignition Control, Red 6425MSD Digital 6AL Ignition Control, Red 6425MSD Digital 6AL Ignition Control, Red 6425MSD Digital 6AL Ignition Control, Red 6425MSD Digital 6AL Ignition Control, Red 6425MSD Digital 6AL Ignition Control, Red 6425MSD Digital 6AL Ignition Control, Red 6425MSD Digital 6AL Ignition Control, Red 6425MSD Digital 6AL Ignition Control, Red 6425MSD Digital 6AL Ignition Control, Red 6425
$493.99 ea
NEWARRIVING SOONEstimated Ship Date 12/23/2024 (If Ordered Today)100 Available from HOLLEY PERFORMANCE PRODUCTS as of 12/05/2024
Model: 2033872
IMPORTANT: Electrical items are covered by a 30 day EXCHANGE ONLY WARRANTY. There are no returns or refunds on such items.
STANDARD
DELIVERY
STORE PICKUP
[More Info]
The MSD 6AL Ignition Control set the standards that other ignitions strive to reach. In fact, you'll find ignitions from other companies that carry the 6AL name (and in some cases, the same part number). MSD raised the bar even higher with the revised Digital 6AL Ignition Control! The wiring of the Digital 6AL is routed out one end of the unit through a sealed and locking connector. This eases installation and keeps your wiring looking neat and clean. The rev-limiter of the 6AL is located right on top of the housing for easy access to the two rotary dials to set the limit in 100 rpm increments. Inside the Digital 6AL, you'll find a microprocessor that monitors and controls every firing and rev limit. The circuits are updated with efficient components that help the ignition produce more power while drawing less current! In fact, the Digital 6AL delivers over 530 volts to the coil with up to 135mJ of spark energy for every firing! Increased output combined with MSD's proven multiple spark series is a win-win situation! The Digital 6AL is supplied with the wiring harness and the components you'll need for installation. The 6AL is also supplied with vibration mounts. Both ignitions are compatible on 4, 6, or 8-cylinder engines with 12-volt, negative ground electrical systems. They'll accept trigger inputs from breaker points, amplifiers, and magnetic pickups.
Features:
  • High output with 530 volts and 135mJ of spark energy
  • Efficient components use less current to produce more power
  • Set an rpm limit with two rotary dials in 100 rpm increments
  • Built-in LED for system checks
  • All wires exit through a locked, sealed connector
  • Compatible with 4, 6 or 8-cylinder engines
CARB EO: D-40-43
Installation Notes:
CARB EO: D-40-43
About MSD Ignition

Racers never stop experimenting as they search for every way to wring out more power or handling performance to to gain an edge over the competition. The team at MSD is no different as we strive to deliver the products you  need to meet your performance goals. We continue to innovate and invent components and technology that deliver  performance and reliability with products that are easy to use and install.

Over the course of 40-plus years, MSD Performance has been driving the development of innovative components  that helped shape the way our cars race and perform. From super speedways to road courses, land speed racing to  top fuel dragsters, and of course your traditional hot rod, MSD has provided the components to fire nearly anything in  motorsports.

MSD was the first company to develop and offer the multiple sparking, capacitive discharge ignition for engines. The line of MSD 6-Series Ignitions are the most popular aftermarket ignitions in the world due to our race-proven performance on the track and our reliability on the street!

Early on, MSD focused squarely on ignition systems with revolutionary products like the multiple sparking CD ignition, timing and rev controls, billet aluminum distributors and the Pro-Mag, an incredible breakthrough in power  and endurance.

Today MSD is developing electronics for your entire powertrain. The Atomic EFI systems for the LS engine platform and throttle body are now complemented with a transmission controller. Our DynaForce Starters and Alternators  ensure that your engine cranks over to fire up and the Alternators keep it charged. MSD is poised to deliver components that work and communicate together to provide performance and value.

Downloads:

Download Name File Size
6201.pdf1.43MB
6425_add.pdf64.07KB

Videos:

Specifications:

Color Red
Current Draw .7 Amp per 1,000 RPM
Emission Code 1
Features Rev Limiter
Part Type Ignition Control Module
Primary Voltage 520-540 Volts
Product Type Digital 6AL Ignition Control Box
Proposition 65 www.P65Warnings.ca.gov
RPM Range 11,000 RPM
Secondary Voltage 45,000 Volts
Spark Energy 135-145 mJ per spark
Voltage Required 12-15 Volts, 7 Volt Start
Warranty Limited 1 Year Warranty
Weight and Size 1.7 lbs., 8"L x 4"W x 1.825"H
